Introducing the next generation of rain resistant louvers, the 2590 wind driven rain louver. The advanced design utilizes centrifugal forces to capture water droplets as the air passes over the sight of proof, drainable blades.The design of the 2590 will improve the weather tightness of the building envelope, while maintaining effective air flow performance required by the ventilation system.

Construction

Depth: 5 1/16"

Material: Extruded 6063-T5 Aluminum

Frame Thickness:  0.081" (2.06 mm)

Frame Styles:Channel Frame Only

Blade Thickness: 0.063" (1.6 mm)

Blade Angle: 35 degrees

Blade Centers: 2 3/4" (70mm)

Minimum Height: 12" (300 mm)

Maximum Panel Height: 120" (3048 mm)

Maximum Panel Width: 60" (1524 mm)

Free Area (48" x 48"): 7.43 sq. ft.

Available Finishes: Mill Finish, Polyester Baking Enamel, Clear or Colored Anodized Finish.

The Model 2620/2625 louver is the extruded aluminum, stationary six inch (150 mm) deep stormproof louver.  The 2620/2625 design provides protection from water penetration while retaining a relatively high free area.   Its sturdy construction makes it ideal for large projects where the louver covers a large span.

Construction

Depth: 6"

Material: Extruded 6063-T5 Aluminum

Frame Thickness:  0.085" (2.16 mm)

Frame Styles: Model 2620 Channel Frame

               Model 2625 Flange Frame 1 1/2"

Blade Thickness: 0.081" (2.06 mm)

Blade Angle: 45 degrees

Blade Centers: 7 1/4" (76.2 mm)

Minimum Height: 16" (400 mm)

Maximum Panel Height: 120" (3048 mm)

Maximum Panel Width: 72" (1830 mm)

Free Area (48" x 48"): 8.06 sq. ft.

Available Finishes: Mill Finish, Polyester Baking Enamel, Clear or Colored Anodized Finish.
